Epoch Batteries 12V 172Ah Dual Purpose Essential Series 12172A-DP | Cranking & Deep Cycle LiFePO4 Battery (2.20kWh) | Bluetooth, IP65, Group 31

Specifications

Model / SKU: 12172A-DP

Series: Essential Series

Battery type: Dual-purpose cranking and deep-cycle LiFePO4 battery

Battery group size: Group 31

Chemistry: LiFePO4 / lithium iron phosphate

Cell type: Prismatic LiFePO4

Cell configuration: 4S1P

Bluetooth: Yes — Epoch Li-Ion app, iOS and Android

Self-heating: No

Cycle life: 4,000+ cycles

Warranty: 11-year manufacturer warranty

Nominal voltage: 12.8V

Nominal capacity: 172Ah

Stored energy: 2.20kWh (2,202Wh, nominal)

Operating voltage range: 10.0V – 14.6V

Maximum charge input: 15.0V maximum input rating — not a charger target (charge at 14.2V – 14.6V)

Max continuous discharge: 200A

Max continuous charge current: 200A, all charging sources combined

Peak discharge / cranking: 1,000A for up to 5 seconds, cranking only

Cranking capability: Approx. 1,000 CCA equivalent

Series / parallel: Parallel only, max. 4 matched batteries (4P: 688Ah, 8.81kWh at 12.8V); series wiring is not approved for this model

Charge temperature range: -5°C to 55°C / 23°F to 131°F (battery rating); program chargers for 0°C to 55°C / 32°F to 131°F

Discharge temperature range: -20°C to 60°C / -4°F to 140°F

Recommended storage temperature: 0°C to 35°C / 32°F to 95°F

Low-temperature charge protection: Yes; the BMS blocks charging when the battery is too cold (no internal heating)

Overall dimensions: 12.91 in L × 6.22 in W × 8.46 in H

Metric dimensions: 328 × 158 × 215 mm

Weight: 40 lb / 18.14 kg

Terminal type: M8 female; torque 8–12 Nm (71–106 in-lb)

Case material: ABS and PC blend

Flame rating: UL94-V0

Enclosure protection: IP65 (IEC 60529): dust-tight, water-jet resistant; not submersible

Bulk / absorption voltage: 14.2V – 14.6V

Absorption end condition: End when current falls to C/20 (about 8.6A) or after 15 minutes, whichever comes first

Float voltage: 13.4V – 13.8V, or disabled (preferred where the charger supports it)

Re-bulk voltage: 13.2V

Equalization: Disabled

Temperature compensation: 0 mV/°C (disabled)

Recommended charge current: Up to 86A (0.5C, 50% of capacity) for one battery; up to 50% of bank capacity for parallel banks

BMS high-voltage cutoff: 14.6V

SOC recalibration voltage: 14.6V

BMS: Smart BMS with built-in battery management

Protections: Overcharge, over-discharge, over-current, short circuit, high temperature, low temperature, and low-temperature charge protection

Cell certification: UL 1642 (cells)

Thermal runaway testing: UL 9540A (cells)

Battery certification: IEC 62619:2022

Compliance: CE, RoHS

Shipping classification: UN 38.3, Class 9

In the Box

• 1 x Epoch 12V 172Ah Dual Purpose LiFePO4 battery (12172A-DP)

12172A-DP Spec Sheet
12172A-DP User Manual
12172A-DP Technical Data Sheet
12172A-DP UN 38.3 Test Report
Epoch LiFePO4 Safety Data Sheet

Epoch Batteries Limited Warranty
